E-Mobility Virtual
prototyping
Insulation systems
Even complex designs can be analyzed and optimized virtually in a fast and and reliable way.
Contacting systems
The functional capability of contacting, plug-in and clamp solutions can be tested virtually with the help of CAD and FEM programs.
Core stack
systems
An essential aspect in the dimensioning of core stacks is the fill factor. AWS can predict fill factors by means of 3D-CAD and can optimize these by adapting the groove geometry.
Increased performance through prototypes
The combination makes it possible:
from a virtual prototype to a hardware prototype
by means of rp technology
Prototypes are particularly useful for fine-tuning
We strive for excellence
Virtual prototypes in e-mobility
AWS offers as a competence center for virtual prototyping as well as for innovative research and development a full range of flexible services: from insulation paper assembly or 3D rapid prototyping of end cap inserts to various contacting designs to the manufacturing of laminated sheet packages.
01
Rapid prototyping
Upon a first virtual analysis the rapid prototyping technology can subsequently help validating the functionality of an idea by hardware based proof of concept models.
02
Contacting
Especially innovative contacting possibilities are predestined for a proof of principle via rapid prototyping.
03
Stator core stacks
Core stack designs for winding trials can also be generated rapidly and economically via rapid prototyping.
Nearly unlimited possibilities for prototypes
Results, functionality and acceptance
AWS offers a full range: pilot series, prototypes, demo examples or functional models can be worked out
